Product Description
The Ubiquiti UniFi U7‑Pro‑XG is a high‑performance Wi‑Fi 7 access point designed for enterprise environments requiring speed, reliability, and scalability. With 6 spatial streams, coverage up to 140 m² (1,500 ft²), and support for 300+ clients, it delivers exceptional throughput and stability for dense deployments.
Powered by a 10 GbE uplink and advanced MU‑MIMO across all bands (2×2 on 2.4 GHz, 5 GHz, and 6 GHz), the U7‑Pro‑XG achieves maximum data rates of 5.8 Gbps (6 GHz), 4.3 Gbps (5 GHz), and 688 Mbps (2.4 GHz). Its Beamforming antennas (6 dBi on 6 GHz, 5 dBi on 5 GHz, 4 dBi on 2.4 GHz) ensure strong, directed signals for optimal performance.
Enterprise‑grade features include wireless meshing, band steering, fast roaming (802.11r), advanced radio resource management, and Hotspot 2.0 (Passpoint). For guest and enterprise networks, it supports captive portal with custom branding, voucher/payment authentication, PPSK, and dynamic VLAN assignment via RADIUS.
Built with a UV‑stabilized polycarbonate and aluminum alloy enclosure, the U7‑Pro‑XG is NDAA compliant and certified for global use. It is managed via UniFi Network software (v9.0.114+ for White, v9.1.120+ for Black), providing centralized monitoring, configuration, and optimization.
Key Features
Wi‑Fi 7 Standard: 6 spatial streams with ultra‑fast multi‑band performance.
High Capacity: Supports 300+ clients with coverage up to 140 m².
10 GbE Uplink: Ensures maximum throughput for enterprise networks.
Advanced MU‑MIMO: 2×2 (6 GHz, 5 GHz, 2.4 GHz).
Seamless Roaming: 802.11r/k/v support with band steering.
Guest & Enterprise Features: Captive portal, PPSK, voucher/payment authentication.
Security: WPA3, RADIUS over TLS, client isolation, VLAN tagging.
Management: UniFi Network application with advanced radio resource management.
Durable Build: UV‑stabilized enclosure, stainless steel mounting, NDAA compliant.
Specifications
Dimensions: ⌀206 × 32.5 mm (⌀8.1 × 1.3")
Weight: 750 g (1.7 lb)
Ports: 1× 10 GbE RJ45
Power: PoE+ (42.5–57V DC), Max consumption 22W
Operating Temp: –30 to 40 °C
Operating Humidity: 5–95% non‑condensing
Certifications: CE, FCC, IC, Anatel
